Product Description

Functional Integration for Miniature Sensor Networks
This M5 circular connector male overmould elbow 90° waterproof IP68 cable connector is engineered to meet the demands of compact industrial automation and sensor arrays. Designed for applications requiring dense sensor configurations in limited space, it serves system integrators and engineers seeking reliable electrical connector manufacturer solutions. Offering both 3 pin waterproof connector and 4 pin waterproof connector variants, it supports optimized signal transmission with a secure screw locking system. Its angled elbow facilitates efficient cable routing, closing gaps in spatially constrained environments and enabling integration with pcb mount circular connector assemblies. This product is suitable for procurement managers sourcing miniature, high-quality connectors from expert circular connector manufacturers.

Robust Technical Specifications and Materials
Constructed with premium brass contacts plated in gold and housed in a molded cable assembly featuring PVC or TPU overmoulding, this connector ensures corrosion resistance and long-term conductivity. Rated at 60V and 1A current capacity, the connector accepts cable diameters from 3 to 5mm, compatible with UL-certified wire types. It adheres to IEC 61076-2-105 standards, incorporating a screw locking system and featuring robust insulation resistance ≥100MΩ and contact resistance ≤10mΩ. Waterproof performance meets IP68 benchmarks, allowing prolonged submersion without compromising integrity. This product represents a precise offering from pcb connector manufacturers aiming at high durability and operational safety in harsh environments.

Applications in Industrial Automation and Sensor Technology
The M5 connector adapts effectively across multiple industries requiring miniature sensor connectivity, including automated production lines and process control systems. Its design supports secure data and power transmissions critical in measurement and control cable assemblies. Compatible with pcb mount circular connector modules, its flexibility in pin configuration supports diverse sensor protocols, simplifying wiring and reducing maintenance time. Its waterproof rating applies not only in field installations exposed to moisture but also in confined industrial settings requiring IP68-rated connectors. As a trusted electrical connector manufacturer product, it facilitates increased system uptime and streamlined sensor network deployment.

Product Advantages

Structural and Design Efficiency in Compact Systems
The 90° male overmould elbow design optimizes space utilization, advancing integration capabilities for compact systems assembled by pcb connector manufacturers. With options for 3 pin waterproof connector and 4 pin waterproof connector configurations, it offers design versatility to meet varying application requirements. The use of brass contacts with gold plating ensures reliable electrical connections, while the screw locking mechanism secures mechanical coupling under vibration or physical stress. The cable overmoulding with PVC or TPU bolsters strain relief and durability, meeting standards expected from top-tier circular connector manufacturers. These design elements collectively enhance ruggedness and extend lifecycle in industrial environments.

Performance and User Convenience in Harsh Environments
This M5 connector guarantees consistent electrical performance with low contact resistance and robust insulation resistance, vital for precision sensor applications. The IP68 waterproof rating assures functionality in wet and corrosive conditions, reducing failure rates in demanding workflows typical for electrical connector manufacturer solutions. Custom cable lengths and selectable cable materials provide adaptability to specific installation constraints, improving installation efficiency and maintenance. The screw locking system facilitates quick assembly and reliable retention, mitigating risks of accidental disconnects. Overall, this product maximizes operational uptime and reduces total cost of ownership for system integrators handling multiple sensor arrays.

Use Scenarios

Sensor Integration in Compact Industrial Automation
In automated manufacturing lines where space is constrained, this M5 connector enables seamless connection of miniature sensors tasked with monitoring production parameters. Its 90° elbow design supports streamlined cable management within compact sensor arrays, facilitating efficient integration with pcb mount circular connector boards. The IP68 waterproof rating and screw locking system assure durability against water ingress and mechanical vibrations common in these settings. Electrical performance metrics guarantee secure signal transmission essential for real-time monitoring and control, while customization options support adaptation to diverse sensor configurations utilized by circular connector manufacturers specializing in industrial automation.

Reliable Connectivity in Harsh, Moist Environments
This 3 pin waterproof connector or 4 pin waterproof connector is suited for applications exposed to moisture, such as outdoor measurement systems or food processing plants requiring stringent hygiene controls. Its overmoulded cable assembly provides enhanced strain relief and protection against contaminants, while the brass gold-plated contacts maintain conductivity under corrosive conditions. The connector’s IP68 compliance ensures continuous submersion protection, aligning with industry standards enforced by electrical connector manufacturer certifications. Integration into multi-sensor setups benefits from its secure screw locking interface, allowing quick disconnects during maintenance without compromising system integrity or performance. This makes it an ideal choice for harsh environment deployments requiring consistent reliability.

FAQ

What cable materials are available for the M5 circular connector?
We offer cable materials including PVC, PUR, and TPU for our M5 circular connector. These options ensure compatibility with diverse industrial environments while maintaining the durability and waterproof performance expected from a leading circular connector manufacturer.

Can I get the M5 connector with custom cable lengths?
Yes, we provide custom cable length options tailored to your requirements. Whether you need specific lengths or cable diameters from 3 to 5mm, our manufacturing process supports flexible wiring solutions for your compact sensor setups.

How do I install the M5 connector securely in my application?
Our M5 connector features a screw locking system that guarantees a secure and durable connection. The 90° overmould elbow design not only facilitates space-saving installation but also simplifies cable routing in tight assemblies, ideal for industrial sensor arrays.

Do you supply connectors suitable for 3-pin and 4-pin configurations?
We manufacture M5 connectors in both 3-pin and 4-pin configurations with A coding to meet varied wiring needs. As a trusted electrical connector manufacturer, we ensure these configurations maintain reliable signal transmission with brass contacts plated in gold for corrosion resistance.
